| Panel thickness |
8 ÷ 60mm |
| Coil edging thickness |
0.4 ÷ 3 mm |
| Max. coil edges section |
135 mm² |
| Max coil diameter |
780 mm |
| Max. edging thickness |
0.4 ÷ 12 mm |
| Feed speed |
12 -18 m/min |
| Max. edging surplus with respect to panel thickness |
2+2 mm |
| Min. panel width using (with length at least 210 mm) |
|
| with panel thickness until 40 mm |
55mm |
| with panel thickness from 41 until 60 mm |
80mm |
| with edge thickness more than 3 mm |
80mm |
| Min. panel length (with width at least 100 mm) |
140mm |
| Min. coil edge length |
170mm |
| Min. Strip edge length |
250mm |
| Distance between two consecutive panels with feed speed 12m/min |
550mm |
| Distance between two consecutive panels with feed speed 18 m/min |
650mm |
| Opening Panel Support Rollers |
600mm |
| Height Working Table |
950-980mm |
| Gluing Unit GP-800 |
| Power absorbed |
3.0 kW |
| Glue tank capacity |
1.5 Kg |
| Heating glue time |
12 min |
| End Trimming Unit IK/S |
| Tool rotation speed |
12,000rpm |
| Blade inclination |
0° - 15° |
| Motor power |
0.35 kW |
| Tilting Trimming Unit TT/1000 |
| Min. panel thickness (TS/K) |
8mm |
| Tool inclination (only TT/1000) |
0° - 25° |
| Min. panel thickness (TT/1000) |
12mm |
| Tool rotation speed |
0.65kw |
| Power of each motor |
12,000rpm |
| Corner Rounding Unit A Super |
| Tool rotation speed |
12,000 rpm |
| Edging Thickness |
0.3-3 mm |
| Workable panel thickness by trimming |
12 - 60 mm |
| Workable panel thickness by rounding |
12 - 45 mm |
| Tool diameter (excluding radius) |
61 x 16 mm |
| Dust extraction outlets |
3 x D=60 mm |
| Power of each motor |
0.35kw |
| Edge Scraping Unit |
| Knives with radius |
2mm |
| Min. panel thickness |
12mm |
| Brushing Unit BFN |
| Motor power |
0.13kw |
| Rotation speed |
1400 RPM |
