Max. Depth Of Cut : 150 mm
Max. Length Of Cut : 330 mm
Transversal Stroke : 80 mm
Max. Working Height For Doors : 1000 mm
Vertical Stroke Of The Work Table : 250 mm
Max. Diameter Of The Vertical Tools : 28 mm
Max. Diameter Of The Horizontal Tools : 40 mm
Mortising Machine Motor’s Power Output : 3 KW
Vertical Unit Motor’s Power Output : 0.55 KW
Horizontal Unit Motor’s Power Output : 1.84 KW
Output Of The Two Oscillating Motors : 0.22 KW
Vertical Tool Speed : 4200 RPM
Horizontal Tool Speed : 8400 RPM
Weight : 850 KG
Dimensions : 950x3150x2100 mm
