| Capacity | 1/8" - 2" (3mm - 50mm) 11 R Die Heads. | |||||||||
| Weight | 21.1 lbs. ( 9.59 kg) Power Drive only. | |||||||||
| Size | 24.1 in. (613 mm) L x 4.75 in. (121 mm) W x 8 in. (203mm) L. | |||||||||
| Controls | Forward/reverse slide switch, on/off two-step momentary contact. | |||||||||
| Gear Head: | Die cast aluminum permanently greased. | |||||||||
| Body & Handle | Durable heavy-duty fiberglass reinforced plastic. | |||||||||
|
CATALOG NUMBER |
MODEL NO. | DESCRIPTION | RPM | VOLTAGE (V) | FREQUENCY (HZ) | PHASE | AMP DRAW (A) | POWER | WEIGHT | |
| LB. | KG | |||||||||
| 44923 | 690-I | Power Drive 1/2" - 2" NPT Die Heads, Case, & Support Arm | 36 | 115 | 60 | 1 | 12 | 1020 W | 59.4 | 26.9 |
| 44928 | 690-I | Power Drive Only W/ Case and Support Arm | 36 | 115 | 60 | 1 | 12 | 1020 W | 42.4 | 19.2 |
| 44933 | 690-I | Power Drive 1/2" - 2" BSPT Die Head, Case & Support Arm | 32 | 230 | 50 | 1 | 5 | 1270 W | 57.2 | 26.0 |
|
ACCESSORIES
|
||||||||||
|
CATALOG NUMBER |
MODEL NO. | DESCRIPTION | WEIGHT | |||||||
| LB. | KG | |||||||||
| 45928 | 692 | 692 Support Arm | 7.0 | 3.2 | ||||||
| 46673 | 690-I Carrying Case | - | - | |||||||
| 39187 | 11-R Ratchet Ring | 1.1 | 0.5 | |||||||
| 10883 | 418 | Oiler with One Gallon Premium Thread Cutting Oil | 20.5 | 9.4 | ||||||
| 16703 | 425 | 425 1/8" - 2-1/2" Portable TRISTAND Chain Vise | 32.0 | 14.5 | ||||||
| 36273 | 460-6 | 460-6 1/8" - 6" Portable TRISTAND® Chain Vise | 42.8 | 19.4 | ||||||
| 73442 | 418 | 418 Oiler | 20.5 | 9.4 | ||||||
| 45588 | 690-I Brush Assembly 230V (2) | - | - |
