| Camera Head | 0.98" (25 mm) | ||
| Cable Length | 100' (30 m) | ||
| Cable Diameter | 0.27" (6,7 mm). | ||
| Line Capacity | 11/2" to 4" or 5" (40 - 100 / 125 mm) | ||
| Weight | 10.3 lbs. (4,7 kg) | ||
| Size | Length 13.25" (33.7 cm), Width 6.6" (16.8 cm), Height 14.2" (36.1 cm) | ||
| Resolution | 510 x 496 | ||
| Ball Guide | 2 included | ||
| Sonde | 512 Hz | ||
| Counter | Optional (L100C) | ||
|
CATALOG NUMBER |
DESCRIPTION | WEIGHT | |
| LB. | KG | ||
| 35133 | microReel L100 (SS CCU) NTSC | 10.30 | 4.70 |
| 35143 | microReel L100 (CA-350) NTSC | 10.30 | 4.70 |
| 40798 | microReel L100/micro CA-350 System NTSC | 11.60 | 5.30 |
|
100' (30 M)
MICROREEL L100C W/SONDE AND COUNTER |
|||
|
CATALOG NUMBER |
DESCRIPTION | WEIGHT | |
| LB. | KG | ||
| 35183 | microReel L100C (SS CCU) Counter NTSC | 10 | 4.70 |
| 35188 | microReel L100C (CA-350) Counter NTSC * | 10 | 4.70 |
| 40808 | microReel L100C/micro CA-350 System NTSC * | 12 | 5.30 |
|
|
|||
|
ACCESSORIES
|
|||
|
CATALOG NUMBER |
DESCRIPTION | WEIGHT | |
| LB. | KG | ||
| 33108 | Interconnect Cable for SeeSnake Monitor | 0.65 | 0.31 |
| 33113 | Interconnect Cable for CA-300/350 Monitor | 0.65 | 0.31 |
| 34623 | microReel L100 Drum Only w/Sonde NTSC | 5.50 | 2.50 |
| 35243 | microReel L100C Drum Only NTSC | 5.50 | 2.50 |
| 35338 | 45 mm Pipe Guide, Fits 25 mm Camera (pkg. of 2) | - | - |
| 40598 | 60 mm Pipe Guide, Fits 25 mm Camera (pkg. of 2) | - | - |
| 46708 | 85 mm Pipe Guide, Fits 25 mm Camera (pkg. of 2) | - | - |
| 46713 | 125 mm Pipe Guide, Fits 25 mm Camera (pkg. of 2) | - | - |
| 47793 | 36 mm Pipe Guide, Fits 25 mm Camera (pkg. of 1) | - | - |
- Lightweight and compact design is one-half the size of popular inspection systems, easily stowed in a truck and carried onto the jobsite
- Multi-monitor compatibility with existing SeeSnake monitors, or the micro CA-300/350 digital inspection camera
- Durable and reliable construction with hardened stainless steel camera head spring assembly for a long service life. Long-lasting high-intensity lights for exceptional viewing
- Stiffer push cable than microDrain to enable line inspections up to 100' (30m)
- Brand: RIDGID
- Product Code: L100, VIDEO INSPECTION SYSTEM
- Catalog Number: 35113 - 35143 - 40798 - 35138
Lightweight and compact design is one-half the size of popular inspection systems, easily stowed in a truck and carried onto the jobsite
