| Line Capacity | 2" - 12" (5-30cm) | |||
| Maximum Run | 325' (99m) | |||
| Sonde | 512 Hz | |||
| Weight | 53 lbs. (19.5 kg) | |||
| Reel Frame Diameter | 32" (81 cm) | |||
| Camera Diameter | 1.365" (35 mm) | |||
| Camera Length | 1.68" (42 mm) | |||
| Push Cable Diameter | .44" (11 mm) | |||
| Operating Temperature | -4˚ to 104˚F (-20˚ to 40˚C) | |||
| Waterproof Depth | 330' (100 m) | |||
| Video Resolution | 656(H) x 492(V) | |||
|
CATALOG NUMBER |
DESCRIPTION | VOLTAGE (V) | WEIGHT | |
| LB. | KG | |||
| 14053 | 200' Color Reel (NTSC) | 115 | 42.0 | 19.0 |
| 14058 | 325' Color Reel (NTSC) | 115 | 53.0 | 24.0 |
| 14103 | 200' Color Reel (PAL) | 230 | 42.0 | 19.0 |
| 14108 | 325' Color Reel (PAL) | 230 | 53.0 | 24.0 |
| 13988 | 200' Self-Leveling Color Reel (NTSC) | 115 | 42.0 | 19.0 |
| 13998 | 325' Self-Leveling Color Reel (NTSC) | 115 | 53.0 | 24.0 |
| 70592 | SeeSnake 200' (61 m) Colour Reel PAL | 230 | 43.0 | 19.5 |
| 70597 | SeeSnake 325' (99 m) Colour Reel PAL | 230 | 53.0 | 24.0 |
| 13993 | SeeSnake 200' (61 m) Self-Leveling Color Reel (PAL) | 230 | 43.0 | 19.5 |
| 14003 | SeeSnake 325' (99 m) Self-Leveling Color Reel (PAL) | 230 | 53.0 | 24.0 |
|
ACCESSORIES
|
||||
|
CATALOG NUMBER |
DESCRIPTION | WEIGHT | ||
| LB. | KG | |||
| 15323 | SeeSnake Flexible In-Line Transmitter | 0.6 | 0.3 | |
| 17563 | Color Spanner Wrench | - | - | |
| 31753 | Count Plus Cable Counter | - | - | |
| 64497 | 75 mm Star Guide, Fits 35 mm Camera (pkg. of 20) | - | - | |
| 64502 | 150 mm Star Guide, Fits 35 mm Camera (pkg. of 10) | - | - | |
| 64627 | SeeSnake Interconnect Cord – 33/10' (10 m / 3m)" | - | - | |
| 93387 | SeeSnake Guide Hoop, Pkg of 4 | - | - | |
| 97832 | SeeSnake 3" (75 mm) Roller Dolly | - | - | |
| 97852 | 85 mm Pipe Guide, Fits 35 mm Camera (pkg. of 10) | - | - | |
|
REPLACEMENT
PARTS
|
||||
|
CATALOG NUMBER |
DESCRIPTION | |||
| 14078 | Color Camera Head – NTSC (115V) | |||
| 48543 | Color Self-Leveling Camera Head – NTSC (115V) | |||
| 64607 | 200' (61 m) SeeSnake Push Cable Assembly | |||
| 64612 | 325' (99 m) Standard SeeSnake Push Cable Assembly |
- Choose SeeSnake standard camera or the self-leveling cameras for always upright images.
- 100% hardened stainless steel camera head spring assembly for optimum durability.
- Rugged, high-intensity lights for exceptional viewing and long life.
- Flexible transmitters make locating easy and are compatible with RIDGID® locators.
- Can be used with any SeeSnake monitor or recorder.
- 2” to 12” (5 – 30 cm) Lines up to 325’ (99 m).
- Wide pipe diameter capacity range makes this system ideal for a wide range of inspection needs.
- Brand: RIDGID
- Product Code: Standard Camera
- Catalog Number: 14053 - 14058 - 14103 - 14108
SeeSnake video inspection systems offer unmatched reliability and performance in a ruggedized package. Each system offers:
