| 1,5 kW 2-4 lt/dak. |
| 18.000 RPM |
| 6-8 Bar |
| 30-130 mm |
| 1800 x 850 x 1600 |
| 160 kg |
|
140 kg
|
- Copy fitting operates manually and the figures on the template are machined at 1:1 ratio
- The aluminium profiles up to 3 mm walls can be conveiently machined with a strong spindle motor.
- The cutting fluid controlled with a joystick is sprayed to the milling spot.
- Canals in varied lengths and widths can be opened without using the copy milling template
- The water evacuation canal lenght on the copy template is adjustable
- Copy milling motor is directly controlled via joystick
- Referance stops the 2 axes of the milling machine
- Inlet-outlet conveyor provided as standard
- Ergonomic hand control unit
- Front profile clamps are standard and top profile clamps are optional.
- Brand: YILMAZ
- Product Code: CRM 200 S
Front profile clamps are standard and top profile clamps are optional.
